Table A- 4: Trigger specifications (Cont.)
Characteristic Description
Trigger level or threshold accuracy, typi cal
CSA7404, CSA7154, TDS7404,
TDS7254, & TDS7154
Edge trigger, DC coupling, f or signals having rise and fall times ≤1ns
Trigger Source Accuracy
Any channel ± [(2% × | setting -- net offset | ) +
(0.35 div × volts/div setting) + offset
accuracy] (≥ 10 mV/div only)
Auxiliary Not specified
where, net offset = offset -- ( position × volts/division)
TDS7104 & TDS7054 Edge trigger, DC coupling, for signals having rise and fall times ≤20 ns
Trigger Source Accuracy
Any channel ± [(2% × | setting -- net offset | ) +
(0.3 div × volts/div setting) + offset
accuracy]
Auxiliary Not calibrated or specified
where, net offset = offset -- ( position × volts/division)
TDS6604, & TDS6404 Edge t ri gger, DC coupling, for signals having rise and fall times >1 ns
Trigger Source Accuracy
Any channel ± [(2% × | setting -- net offset | ) +
(0.35 div × volts/div setting) + offset
accuracy] (≥ 10 mV/div only)
Auxiliary Not specified
where, net offset = offset -- ( position × volts/division)
B Event (Delayed) trigger Trigger After Time Trigger on n
th
Event
Range Delay time = 16 ns to 250 s Event count = 1 to 10
7
Minimum time between arm (A Event)
and trigger (B Event), typical
2 ns from the end of the time period to
the B trigger event
2 ns between the A tri gger event and the
first B trigger event
Minimum pulse width, typical — B event width ≥1ns
Maximum frequency, typical — B event frequency ≤500 MHz
