Appendix A: Specifications
A-38
CSA7000 Series, TDS7000 Series, & TDS6000 S eries Instruments User Manual
Table A- 10: Mechanical specifications (Cont.)
Characteristic Description
Dimensions
Benchtop configuration With front cover Without front cover
278 mm (10.95 in) height
330 mm (13 in) with feet extended
455 mm (17.9 in) width
435 mm (17.13 in) depth
277 mm (10.9 in) height
330 mm (13 in) with feet extended
455 mm (17.9 in) width
426 mm (16.75 in) depth
Rackmount configuration (Option 1R) With rack handles Without rack handles
267 mm (10.5 in) height
502 mm (19.75 in) wi dth
486 mm (19.13 in) depth
267 mm (10.5 in) height
482 mm (19 in) width
435 mm (17.13 in) depth
Cooling Fan-forced air circulati on with no air filter
Required clearances Top 0mm(0in)
Bottom 19 mm (0.75 in) minimum or
0 mm (0 in) when standing on feet, flip
stands down
Left side 76 mm (3 in)
Right side 76 mm (3 in)
Front 0mm(0in)
Rear 0 mm (0 in) on rear feet
Construction material Chassis parts are constructed of aluminum alloy, front panel is constructed of plastic
laminate, circuit boards are constructed of glass lami nate, and the outer shell is
molded and textured from a polycarbonate/ABS blend
Table A- 11: Environmental specifications
Characteristic Description
Temperature, operating 0 °Cto+50 °C(32 °F to +122 °F), excluding floppy disk and compact disk drives
+10 °Cto+45 °C(50°Fto+113°F), including floppy disk and compact disk drives
Nonoperating -- 2 2 °Cto+60°C(71°F to +140 °F)
