Tektronix THDP0100 User Manual

Adjustments
7. Using the narrow-bladed tool, adjust the DC CMRR pot in the probe to minimize the amplitude of the waveform displayed
on the o scillos
cope. Use averaging or hi-res filters to m ake viewing the 40 H z signal easier.
WARNING. Use only an insulated tool to make the adjustment. Failure to do so presents a potential shock hazard.
8. Disable the genera
tor output.
THDP0100/0200 & TMDP 0200 High Voltage Differential P robes Instruction Manual 48
