Tektronix TPS2014B User Manual

Appendix A: TPS2000B Specifications
Table 5: Trigger Specifications (cont.)
Characteristics Description
Signal Formats and Field
Rates, Video Trigger Type
Supports NTSC, PAL, and SECAM broadcast systems for any field or any line
Holdoff Range
500 ns to 10 s
1
Available only on a 4-channel oscilloscope.
2
TPS2024B only.
Table 6: Pulse Width Trigger Specifications
Characteristics Description
Pulse Width Trigger modes
Trigger when < (Less than), > (Greater than), = (Equal), or ≠ (Not Equal); Positive pulse or
Negative pulse
Pulse Width Trigger Point
Equal: The oscilloscope triggers when the trailing edge of the pulse crosses the trigger level.
Not Equal: If the pulse is narrower than the specified width, the trigger point is the trailing edge.
Otherwise, the oscilloscope triggers when a pulse continues longer than the time s pecified as
the Pulse Width.
Less than: The trigger point is the trailing edge.
Greater than (also called time-out trigger): The oscilloscope triggers w hen a pulse continues
longer than the time specified as the Pulse Width.
Pulse Width Range
Selectablefrom33nsto10s
Pulse Width Resolution 16.5 ns or 1 part per thousand, whichever is larger
Equal Guardband t > 330 ns: ±5% ≤ guardband < ±(5.1% + 16.5 ns)
t ≤ 330 ns: guardband = ±16.5 ns
Not Equal Guardband t > 330 ns: ±5% ≤ guardband < ±(5.1% + 16.5 ns)
165 ns < t ≤ 330 ns: guardband = -16.5 ns ÷ +33 ns
t ≤ 165 ns: guardband = ±16.5 ns
Table 7: Trigger Frequency Counter Specifications
Characteristics Description
Readout Resolution 6 digits
Accuracy (typical) ±51 parts per million including all frequency reference errors and ±1 count errors
Frequency Range
AC coupled, 10 Hz minimum to rated bandwidth
Signal Source
Pulse Width or Edge Trigger modes: all available trigger sources
The Frequency Counter measures trigger source at all times in Pulse Width or Edge m odes,
including when the oscilloscope acquisition is halted due to changes in the run status, or acquisition
of a single shot event has completed.
Pulse Width Trigger mode: The oscilloscope counts pulses of significant magnitude inside the
250 ms measurement window that qualify as triggerable events, such as narrow pulses in a PWM
pulse train if set to < mode and the width i s set to a relatively small time.
Edge Trigger mode: The oscilloscope counts all edges of sufficient magnitude and correct polarity.
Video Trigger mode: The Frequency Counter does not operate.
TPS2000B Series Digital Oscilloscope User Manual 127
