Reference
Utility
Push the Utility button t o display the U tility Menu.
Options Settings Comments
System Status Summary of the oscilloscope settings
Front Panel Backlight
Enables Illumination of the front panel
Printer Setup Displays the setup for the printer (See page 72, Printer
Setup.)
RS232 Setup Displays the setup for the RS-232 port (See page 73.)
Set Date and Time Sets the date and time (See page 118.)
Options
Error Log
Displays a list of any errors logged and the Power Cycle
count
This log is useful if you contact a Tektronix Service Center
for help.
Do Self Cal Performs a self calibration
File Utilities
Displays folder, file, and CF card options (See page 11 9.)
Language
English, French, German, Italian,
Spanish, Japanese, Portuguese,
Simplified Chinese, Traditional
Chinese, Korean
Selects the display language of the oscilloscope
Key Points
System Status. Selecting System Status from the Utility Menu displays the m enus
available for obtaining a list of control settings for each group of oscilloscope
controls.
Push any front-panel menu button to remove the status screen.
Options Comments
Horizontal Lists horizontal parameters
Vertical
Lists vertical parameters of channels
Trigger Lists trigger parameters
Misc
Lists the model of the oscilloscope, the version number of the
software, and the serial number
Lists the charge status of the battery packs
Lists values of the communications parameters
Setting the Date and Time. You can use the Set Date and Time menu to set the
clock date and time. The oscilloscope displays this information, and also uses it
to time stamp files written to the CF card. The oscilloscope contains a built-in
nonreplaceable battery to maintain the clock settings.
The clock does not automatically adjust for seasonal time changes. The calendar
does a djust for Leap years.
118 TPS2000B Series Digital Oscilloscope User Manual
