Appendix B: TPP0101 and TPP0201 Series 10X Passive Probes Information
Optional Acce
ssories
You can order the following ac cessories for your probe.
Accessory Part num ber
Alligator Ground Lead, 12 in
196-3512-xx
6” Clip-on Ground Lead
196-3198-xx
Ground Spring, Short, 2 ea.
016-2034-xx
MicroCKT Test Tip
206-0569-xx
Micro Hook Tip 013-0363-xx
Universal IC Cap
013-0366-xx
Circuit Board Test Point/PCB Adapter
016-2016-xx
Wire, spool, 32 AWG
020-3045-xx
Specifications
Table 10: Electrical and mechanical specifications
Characteristic TPP0101 TPP0201
Bandwidth (–3 dB) DC to 100 MHz DC to 200 MHz
System attenuation accuracy 10:1 ±3.2% 10:1 ±3.2%
Compensation range
TPP0101:
15 pF – 25 pF
TPP0201:
15 pF – 25 pF
System input resistance
@DC
10 MΩ ±1.5% 10 M Ω ±1.5%
System input capacitance
<12 pF <12 pF
System rise time (typical)
<3.5 ns <2.3 ns
Propagation delay ~6.1 ns ~6.1 ns
Maximum input voltage
300 V
RMS
CAT II 300 V
RMS
CAT II
Cable length
1.3 m 1.3 m
Table 11: Environmental specifications
Characteristics Description
Temperature
Operating
Nonoperating
–10 °C to +55 °C (14 °F to +131 °F)
–51 °C to +71 °C (–60 °F to +160 °F)
Humidity
Operating and
Non-Operating
5% to 95% relative humidity (%RH) up to +30 °C (86 °F), 5% to
65% RH above +30° C up to +55 °C (131 °F)
Altitude
Operating
Nonoperating
3.0 km (10,000 ft) maximum
12.2 km (40,000 ft) maximum
134 TPS2000B Series Digital Oscilloscope User Manual
