Reference
Measure
Push the Measure button to acce ss automatic measurements. There are eleven
types of measurements available. You can display up to five at a time.
Push the top option button t o display the Measure 1 Menu. You can choose the
channel on which to take a measurement in the Source option. You can choose the
type of measurement to take in the Type option. Push the Back option button to
return to the Measure Menu and display the selected measurements.
Key Po ints
Taking Measurements. Youcandisplayuptofive automatic mea surements at a
time. The w aveform channel must be on (displayed) to make a measurement.
Automated measurements cannot be taken on reference waveforms, or w hile
using XY or scan mode. The measurements update about two times per second.
Measurement type Definition
Freq
Calculates the frequency of the waveform by measuring the first cycle
Period
Calculates the time of the first cycle
Mean
Calculates the arithmetic mean amplitude over the entire r ecord
Pk-Pk
Calculates the absolute difference between the maximum and
minimum peaks of the entire waveform
Cyc RMS Calculates a true RMS measurement of the first complete cycle of
the w aveform
Min
Examines the entire 2500 point waveform record and displays the
minimum value
Max
Examines the entire 2500 point waveform record and displays the
maximum value
Rise Time
Measures the time between 10% and 90% of the first rising edge of
the w aveform
Fall Time
Measures the time between 90% and 10% of the first falling edge of
the w aveform
Pos Width
Measures the time between the first rising edge and the next falling
edge at the waveform 50% level
Neg Width
Measures the time between the first falling edge and the next rising
edge at the waveform 50% level
None Does not take any measurement
Print
When the Save/Recall ► Save All ► Print Button option is set to Prints, you
can push the
print button to send the screen image to a printer or computer.
You can set up the oscilloscope to send a screen image to your p rinter through the
Utility ► Options ► Printer Setup menu. (See page 72, Printer Setup.)
TPS2000B Series Digital Oscilloscope User Manual 107
