Appendix B: TPP0101 and TPP0201 Series 10X Passive P robes Information
Standard Acce
ssories
The accessories included with the probe are shown below.
Item Description
Color bands
Use these bands to identify the oscilloscope channel
at the probe
head.
Reorder Tektronix part number 016-0633-xx (5 pairs)
Hook tip
Press the hook tip onto probe tip and then clamp the
hook onto the circuit.
Reorder Tektronix part number 013-0362-xx
Ground lead, with a lligator clip
Secure the lead to the probe head ground and then to
your circuit ground.
Reorder Tektronix part number 196-3521-xx
Ground spring
The ground spring minimizes aberrations on
high-frequency signals caused by the inductance of
the ground path, giving you measurements with good
signal fidelity.
Attach the spring to the ground band on the probe tip.
You can bend the spring out to ~0.75 in. away from
the signal test point.
Reorder Tektronix part number 016-2028-xx (2 ea.)
Adjustment tool
Reorder Tektronix part number 003-1433-xx
TPS2000B Series Digital Oscilloscope User Manual 133
