Teleco TVPLA868CC2 - Index; Warnings

2
INDEX
1. Connections, adjustments and control unit warnings page 3
2. MOTOR CONFIGURATION ---------------------------------- pages 4 - 7
2.1 Pergola with 1 motor
2.2 Pergola with 2 synchronized motors
2.3 Pergola with 2 independent motors
2.4 Setting of the current threshold during conguration
3. TRANSMITTERS ------------------------------------------- pages 8 - 10
3.1 Radio codes memorization
3.2 Radio codes deletion
3.3 Remote memorization of other radio codes
3.4 Remote deletion of a radio code
4. SENSORS -------------------------------- pages 11 - 13
4.1 WIND sensor
4.2 SNOW condition
4.3 TEMPERATURE sensor
4.4 RAIN sensor
4.5 Modication of the alarm automatic angles
5. FURTHER DETAILS ---------------------- page 14
5.1 Troubleshooting (what to do IF...)
5.2 Replacing the control unit
5.3 Quick learning of limit switches
6. Technical specications ---------------------- page 15
WARNINGS
The product at issue must be installed, commissioned and maintained only by licensed and authorised people, respecting the laws
concerning the automatic covers. The system is powered by 24V . Before the connection to the power supply make sure that the sensors
and motors are correctly connected. A faulty connection of the motors (polarity inversion) could damage them together with the connected
mechanical elements. The power supply must supply the required voltage and current according to the characteristics of the system. The power
supply must be compliant with IEC60950-1 and must be protected against the short-circuit and over-voltage. Use a 2x1.5mm cable to connect
the motors and the control unit for length up to 6m, or 2x2.5mm cable for longer segments. PRODUCT DISPOSAL: at the end of this product’s
useful life, it must not be disposed of as domestic waste, but must be taken to a collection centre for waste electrical and electronic equipment.
To prevent inltration of water, wire the product as follows:
The manufacturer, Teleco Automation s.r.l, declares that the type of radio equipment is compliant with Directive 2014/53 / EU. The full text of the EU compliance declaration is available at the following Internet
address: www.telecoautomation.com/ceIn the view of a constant development of their products, the manufacturer reserves the right for changing technical data and features without prior notice.
