Telecom Behnke 5 Series Instructions

200
210
100
110
Front view In-wall housing
Necessary cavity space for mounting a 106 mm x
205 mm housing
Dimensioning of series 10 Toscana and
Kayser available at:
www.behnke-online.de/bemassung
40
100
106
200
205
▸
Hohlwandmontage z. B. in bauseitigen Säulen etc. Hier auf die ausreichende
Be- und Entlüftung des Baukörpers achten um einer Kondensatbildung
vorzubeugen.
▸
Depth with electronics: ca. 30 mm
▸
We suggest a cavity of 43-53 mm
deep (incl. space for wiring)
▸
Drilling with M3 screw thread=
200
Necessary
hollow
100
Width 95 mm
Height 190 mm
M3
Mounting (without housing)
7.3. Flush and on-wall mounting Series 10
Dimensions
64 www.behnke-online.com
GB
Instructions for Series 5 / 10
