Page 75
Maintenance Procedures
The spare parts kit 71JK6004-00 includes parts, which are expected to wear out and need to be replaced
on a regular schedule.
Table 3. Spare Parts Kit 71JK6004-00
Part Number Description Quantity
8000585 SPRING, TENSION ARM, ALTERED ITEM 1
8000589 LevelWind Roller, Vertical, rapidCAST 2
8000595 LevelWind Roller, Horizontal, rapidCAST 2
81J-6000-00 SHACKLE, TAILSPOOL, UCTD 1
9000994 LINE, WINCH, RCAST/UCTD, 500LB, WHITE 1500.00 yards
9000996 LINE, WINCH, RCAST/UCTD, 800LB, RED 700.00 yards
9002064 Stainless Steel External Retaining Ring for 6mm Shaft Diameter 2
9002086 Quick-Release Pin, Type 316 Stainless Steel, 1/4" Diameter, 2.5" Usable Length 1
9002202 Trapezoidal Tooth Neoprene Timing Belt, .200" Pitch, Trade Size 220xL, 22" Outer Circle, 3/8"
Wide
1
9092K72 CAP, VINYL, 1.75" SQUAREX 1" INSIDE HEIGHT, BLACK 1
9234052 CAP, 0.75"X0.81", VINYL 1
