PRODUCT DESCRIPTION
Echotrac E20 Operator's Manual8
p. 17 of 60
November 25, 2020
Version 8
Uncontrolled Technology Subject to Restrictions Contained on the Cover Page.
Name
High freq.
Low freq.
Description
DUAL FREQUENCY
Odom HM200/12-8/20
200kHz, 8°
12kHz, 20°
200/12kHz, 8/20°, hull mount, T197
housing
Odom HM210/12-8/20
210kHz, 7.5°
12kHz, 20°
210/12kHz, 7.5/20°, hull mount, T196
housing
Odom HMBB200/24-4/20
200kHz, 4°
24kHz, 20°
200/24kHz, 4/20°, hull mount, M175-2
housing
Odom OTS200/33-8/23
200kHz, 7°
33kHz, 23°
200/33kHz, 7/23°, over the side, M191
housing
Odom OTSBB200/24-4/20
200kHz, 4°
24kHz, 20°
200/24kHz, 4/20°, over the side, M42
housing
Odom OTSBB200/33-5/23
200kHz, 5°
33kHz, 23°
200/33kHz, 5/23°, over the side, M177-2
housing
Odom THP200/24-4/20
200kHz, 4°
24kHz, 20°
200/24kHz, 4/20°, tank, hull, pole, M108
housing
RESON TC2122
200kHz, 10°
33kHz, 22°
200/33kHz, 10/22°
RESON TC2178
200kHz, 9.5°
33kHz, 22°
200/33kHz, 9.5/22°, hydrodynamic, over
the side applications
Airmar M42-200/24
200kHz, 5°
24kHz, 20°
200/24kHz, 5/20°
Airmar M177-200/33
200kHz, 8°
33kHz, 23°
200/33kHz, 8/23°
Airmar M191 200/33
200kHz, 7°
33kHz, 23°
200/33kHz, 7/23°
Airmar R509LM 28-60/80-130
NB
120kHz, 8°
60kHz, 7°
130/60kHz, 8/7°, narrow band
Airmar R509LM 28-60/80-130
WB
105kHz, 10°
45kHz, 10°
105/45kHz, 10/10°, wide band
Airmar M563 35/100
100kHz, 10°
35kHz, 12°
100/35kHz, 10/12°
Airmar M563 200/40 NEW
200kHz, 4°
40kHz, 16°
200/40kHz, 4/16°
Airmar M563 200/28 NEW
200kHz, 4°
28kHz, 22°
200/28kHz, 4/22°
Neptune T196
210kHz, 7.5°
12kHz, 20°
210/12kHz, 7.5/20°, deep water, hull mount
Neptune T197
200kHz, 8°
12kHz, 20°
200/12kHz, 8/20°
Kongsberg Simrad 38/200 D
200kHz, 7°
38kHz, 17°
200/38kHz, 7/17°
2.4 Supported Auxiliary Sensors
Table 5: Supported auxiliary sensors
Position/Time
Motion
5
TSS1
NMEA GGA
EM1000
NMEA GLL
EM3000
NMEA ZDA
OCTANS TAH
Up to 10Hz sample rate
Up to 50Hz sample rate
5
Only the heave component is used by the E20.
