SERIAL AND UDP OUTPUT STRING FORMATS
Echotrac E20 Operator's Manual
p. 55 of 60
November 25, 2020
Version 8
Uncontrolled Technology Subject to Restrictions Contained on the Cover Page.
Table 21: DESO DDV Draft
Character #
Character
Description
1
D
Always D
2
G
Always G
3-4
DD
Draft data
5
.
Period
6-7
DD
Draft data decimal
8
<sp>
Space
9
m
meters
10
<sp>
Space
11
CR
Carriage return
12
LF
Line feed
Example: DG<sp>DD.DD<sp>m<sp><CR><LF>
= DG<sp>00.00<sp>m<sp><CR><LF>
= Draft 0.00 meters
Table 22: DESO DDV Sound Velocity
Character #
Character
Description
1
C
Always C
2
S
Always S
3-6
DDDD
Sound velocity data
9
<sp>
Space
10-12
m/s
meters per second
13
CR
Carriage return
14
LF
Line feed
Example: CSDDDD<sp>m/s<CR><LF>
= CS1500<sp>m/s<CR><LF>
= Sound velocity 1500 meters per second
