Echotrac E20 Operator's Manual8
Uncontrolled Technology Subject to Restrictions Contained on the Cover Page.
5 OPERATION
5.1 Get Started
Once you have configured the E20 (see section
4.4.1Transducer Configuration), the SBES UI will
guide you through the next steps to get ready for
operation.
When restarting the echosounder, the system
applies the settings last used. The Get Started
screen is displayed, semi-filled in with only the
last two steps remaining. The operator just needs
to select the desired mode for operation (see
section 5.2 below), and then the pinging starts.
5.2 Operation Modes
The Echotrac E20 is an extremely robust and reliable hydrographic echosounder. Its main operation
parameters may be maintained autonomously (fully or partially) or manually.
Figure 8: Operation modes
