User Manual
24
Field
Description
Wireless
Channel
Select the wireless channel from the pull-down menu.
It is different for different country.
802.11 Mode
Select the appropriate 802.11 mode based on the
wireless clients in your network. The drop-down menu
options are 802.11b, 802.11g, 802.11n, 802.11b/g,
802.11n/g and 802.11b/g/n.
Band Width
Select the appropriate band of 20M, 40M or 20M/40M
from the pull-down menu.
Click Apply to save the settings.
3.2.3.2 Wireless Security
In the Wireless page, click Wireless Security. The page shown in the following
figure appears. Wireless security is vital to your network to protect the wireless
communication among wireless stations, access points and wired network.
Note:
Enable Wireless before configuring the wireless security settings in
this page. Refer to 3.2.3.1 Wireless Basic.
When the Security Mode is set as WEP, the following figure appears.
