R309 AT Commands
©2015 Telegesis (UK) Ltd - 114 - AT Command Manual (Rev 3.09)
Overview of Actions
0302
Clear S46
0400
Show status on PA7. LED on (pin driven low) = no connection. Blinking fast = Auto-
searching for PAN. Blinking slow = connected to PAN. The accompanying counter register
defines the update interval. Note: PA7 must be defined to be an output.
0401
Show status on PB7. LED on (pin driven low) = no connection. Blinking fast = Auto-
searching for PAN. Blinking slow = connected to PAN. The accompanying counter register
defines the update interval. Note: PB7 must be defined to be an output.
0402
Show status on PA6. LED on (pin driven low) = no connection. Blinking fast = Auto-
searching for PAN. Blinking slow = connected to PAN. The accompanying counter register
defines the update interval. Note: PA6 must be defined to be an output.
2000
When triggered the number of times listed in the accompanying counter a message is sent
to the sink containing a transmission counter and the reading of the analogue and digital
inputs. Note: Can only be triggered by setting S23, S24, S25 or S26 to 24XX.
2001
When enabling this action the command line is disabled and as soon as a number of bytes
in excess of the number N specified in the accompanying timer/counter register is received
on the serial port, a SCAST containing these characters is sent to the network’s sink.
Notes: This event is triggered by receiving a character on the serial port. N ≤ 64. N must be
written as a 4-character hexadecimal number. This function can only be stopped by
overwriting the register that contains code 2001 from another node.
2002
Sends input from the serial port as a unicast to the node whose address (EUI, network
address or table entry) is stored in S3B. The message will be sent when either no more
data has come for 20ms or the packet is full. The accompanying timer register is not used.
2100
The contents of S3B is sent to the local command line followed by carriage return.
Note: No AT-Prefix required!
2101
The contents of S3C is sent to the local command line followed by carriage return.
Note: No AT-Prefix required!
24XX
Start timers masked in XX.
25XX
Toggle timers masked in XX.
26XX
Stop timers masked in XX.
3XXX
Change I/O port to the LSBs.
4XXX
Change data direction of the I/O port to the LSBs.
53xx
Toggle I/Oxx
54xx
Flash I/Oxx (pull low) for 250ms
55xx
Set I/Oxx to 0
56xx
Set I/Oxx to 1
Table 7. Built-in functions
