R309 AT Commands
©2015 Telegesis (UK) Ltd - 27 - AT Command Manual (Rev 3.09)
+RTABLE – Display Routing Table (ZDO)
Read Command
AT+RTABLE:XX,<address>
Where XX is the start index of the remote
Routing table and <address> can be the remote
node’s EUI64, Network address or address table
entry.
Note
Also the local node can be the target of this
command (e.g. use address table entry FF as
the address)
Use on
FFD, COO as the target device
Response
SEQ:XX
OK or ERROR<errorcode>
This command requests the target node to
respond by listing its routing table starting from
the requested index.
Prompt (example)
RTable:<Network
address>,<errorcode>
Length:40
No.| Dest | Next | Status
00.| 1234 | ABCD | 00
01.| 4321 | 739D | 00
02.| 0000 | 0000 | 03
In this example the routing table of the remote
node with the short ID shown in <Network
address> contains 64 entries (hexadecimal
0x40), of which the first three are displayed.
When the table contains more than the
displayed entries it may be required to repeat
this command and increase the index count until
the full table is derived.
The status shown is as described in table 2.128
of the ZigBee Specification.
In case of an error an errorcode other than 00
will be displayed and the prompt will end after
the errorcode.
SW release
R303 ●
