SNMP write community private
Table 4. Default communication settings
There are two sets of IP/mask/gateway parameters: the ones is use (read-only)
and the ones configured manually. The manually configured settings are taken
into use when the 'IP address configuration' is commanded to manual mode. At
this point the settings' validity is checked. If any of the following is true, IP
address configuration mode is internally changed back to DHCP/AutoIP:
− IP address is 0.0.0.0
− Netmask is 255.255.255.255 or illegal, e.g. 255.128.255.0
− Default gateway address is not in the same subnet
The reset button can be used to restore factory default communication settings
if communication to the unit is lost due to e.g. unknown IP address.
Management interfaces
SNMP communication
CXE85x's SNMP agent uses the factory default communities read: public and
write: private.
The recommended configuration tool for CXE85x is Teleste CATVisor
Commander. Viewer package DUS100 version 4.23 and above contain SNMP
viewer for CXE85x, for detail see "Viewer pages" chapter.
To establish communication with CATVisor Commander, select "Remote" /
"SNMP Element" from the "Add new connection" dialog, then enter the IP
address and correct SNMP communities.
It is also possible to use a 3rd party SNMP browser / manager software to
control and monitor CXE85x. The required Teleste SNMP MIBs can be
downloaded from Teleste Club and SCTE MIBs from SCTE website.
CXE85x can send SNMP traps to 2 separate IP addresses, with separate trap
community and port settings. The trap sending behaviour can be fine-tuned with
delay, interval and lifetime parameters.
The reset button can be used to restore factory default communication settings
if communication to the unit is lost to for example unknown SNMP community.
