4 Installation and Programming Manual - СА62 Alarm Control Panel
SECTION 1: INSTALLATION
1. Introduction
The СА62 alarm control system is an upgraded version of СА60plus and is designed for security and protection of resi-
dential and ofce buildings. The system is based on a modular principle.
The programming of CA62 can be done by two types of keyboards (LED or LCD) or remotely via ProsTE software.
The security control is managed by means of a keyboard or a proxi reader.
General specications of СА62 alarm control panel:
Inputs: • 6 inputs for connecting detectors (5 inputs on the panel and 1 in the keyboard).
Zones: • From 6 to 12 zones with freely programmable parameters.
• Doubling the zone number in the panel by means of specic connection of the detectors.
• Individually settings for the balancing type of each input - one or two balancing resistors or zone doubling.
Partitions: • Two fully independent partitions in the system.
• Arming modes:
- Full (Arming of all zones in the system);
- Instant (Partial arming - the user is allowed to stay in some zones; the entry zone is secured and any intru-
sion will starts the alarm immediately;
- Stay (Partial arming - the user is allowed to stay in some zone; the entry zone is secured, an entry time
will start up in case of an intrusion).
• Security control by means of Proximity cards reader PR62.
• Auto Arming mode for arming the security areas in preprogrammed time.
Outputs: • 3 weak current and 1 power current programmable outputs type ОС (open collector).
• Same options for programming of all outputs.
Codes: • 4 or 6 digits access codes.
• 20 User codes, 4 Manager codes, 1 Engineer code.
• Programmable function “Ambush code” - generates a "silent" panic alarm, when the user is forced to
disarm the system.
• Supervised access of the Engineer to the programmed parameters in the system.
Events LOG:
• Memory LOG for 256 events with time and date - can be viewed by a keyboard or via
ProsTE software.
Report to a
Monitoring
Station:
• Built-in digital communicator for central station monitoring via telephone line. “Contact ID” and “SIA” stand-
ard protocols are supported.
• AJAX - LAN (TCP/IP) communication module.
• VD60 - Voice dialer.
Peripheral
Devices:
• Up to 4 keyboards - LED and/or LCD models.
• Up to 2 proximity cards readers - PR62.
• Supported keyboards for CA62:
- LED61 - Keyboard with LED display up to 6 zones.
- LED62 - Keyboard with LED display up to 12 zones, supports operation with 2 Partitions (A and B).
- LED63 VG SE - Keyboard with LED display up to 12 zones, supports operation with 2 Partitions (A and B).
- LCD62 - Keyboard with icon LCD display up to 6 zones.
- LCD62В - Keyboard with icon LCD display up to 6 zones (blue backlight of the display).
- LCD63 - Keyboard with icon LCD display up to 6 zones with option for voice messages.
- LCD63SE - Keyboard with icon LCD display up to 12 zones with option for voice messages, supports
operation with 2 Partitions (A and B).
- LCD64 - Keyboard with icon LCD display up to 12 zones, supports operation with 2 Partitions (A and B).
• All keyboards have 1 built in zone and quick access buttons.
• Flexible programming of the buttons functions for arming and disarming the partitions in the system.
Programming: • The alarm panel parameters can be programmed from every keyboard (LED or LCD) in the system.
• Programming via PC with
ProsTE software (RS232 serial bus) or via telephone line.
• 4 default congurations of the system parameters, used for basic programming of 3 typical and 1 general
system congurations.
Technical
Specications:
• Transformer - 17 VAC, 17 VA.
• Accumulator charger - 13.8 V, 1A, electronic overload protection.
• Back-up power supply - accumulator 12 V, 7,2 Ah.
• Current consumption - up to 100 mA for the control panel.
• Power supply for detectors - 13.8 V, 1A, electronic overload protection.
• Power supply for additional devices - 13.8 V, 1A, electronic overload protection.
• Operating temperature - from 0°C to +50°C.
• ABS Plastic box - dimensions: 315 х 260 х 80 mm.
• Weight - 2.42 kg.
