70 SUPPLEMENTS - СА62 Alarm Control Panel
SUPPLEMENT D - Algorithms for Operation of ZONES with Key-Switch Type
In the tables below is described the working algorithm for Key-Switch type zones, according to the programmed at AD-
DRESS 2013 parameter - Pulse or Latch. The operation of the Partition(s) and the sounder(s) is described on the right
side of the tables. The operation strongly depends on the current status of the specied parameters pointed out on the
left side of the table. To follow the operation of a partition and/or sounder the installer has to know what is the current
status of the system and what attributes and parameters have been programmed before that.
Algorithm for Key-Switch type zones operating, Latch parameter set on,
when the zone is attached to ONE Partition
Partition
ARMing status
Sounder
status
Operation at zone activating Operation at zone de-activating
Partition Sounder Partition Sounder
DISARMED OFF ARMING - - -
DISARMED ON ARMING STOP - -
ARMED OFF - - DISARMING -
ARMED ON - - DISARMING STOP
Algorithm for Key-Switch type zones operating, Latch parameter set on,
when the zone is attached to TWO Partitions
Part. A
ARMing
Status
Part. B
ARMing
Status
Sounder
A
Sounder
В
Operation at zone activating Operation at zone de-activating
Partition
A
Partition
В
Sounder
А
Sounder
B
Partition
A
Partition
В
Sounder
А
Sounder
B
Disarmed Disarmed OFF OFF Arming Arming - - - - - -
Disarmed Disarmed ON OFF Arming Arming STOP - - - STOP -
Disarmed Disarmed OFF ON Arming Arming - STOP - - - STOP
Disarmed Disarmed ON ON Arming Arming STOP STOP - - STOP STOP
Armed Disarmed OFF OFF - Arming - - Disarming - - -
Armed Disarmed ON OFF - Arming STOP - Disarming - STOP -
Armed Disarmed OFF ON - Arming - STOP Disarming - - STOP
Armed Disarmed ON ON - Arming STOP STOP Disarming - STOP STOP
Disarmed Armed OFF OFF Arming - - - - Disarming - -
Disarmed Armed ON OFF Arming - STOP - - Disarming STOP -
Disarmed Armed OFF ON Arming - - STOP - Disarming - STOP
Disarmed Armed ON ON Arming - STOP STOP - Disarming STOP STOP
Armed Armed OFF OFF - - - - Disarming Disarming - -
Armed Armed ON OFF - - STOP - Disarming Disarming STOP -
Armed Armed OFF ON - - - STOP Disarming Disarming - STOP
Armed Armed ON ON - - STOP STOP Disarming Disarming STOP STOP
Algorithm for Key-Switch type zones operating, Pulse parameter set on,
when the zone is attached to ONE Partition
Attribute
Disarm
Enable
Partition
ARMing status
Sounder
status
Operation at incoming
impulse from the zone
Partition Sounder
Enabled DISARMED OFF ARMING -
Enabled DISARMED ON - STOP
Enabled ARMED OFF DISARMING -
Enabled ARMED ON DISARMING STOP
Disabled DISARMED OFF ARMING -
Disabled DISARMED ON - STOP
Disabled ARMED OFF - -
Disabled ARMED ON - STOP
