ML865G1 HW Design Guide
1VV0301632 Rev. 4 Page 12 of 86 2020-09-23
2. GENERAL PRODUCT DESCRIPTION
Overview
The ML865G1 module is a CATM / NBIoT / 2G communication product which allows
integrators to plan on availability for even the longest lifecycle applications, highly
recommended for new designs specified for coverage worldwide.
The ML865G1 operates with 1.8 V GPIOs, minimizing power consumption and making it
even more ideally suited for battery powered and wearable device applications.
Product Variants and Frequency Bands
Product 2G Band (MHz) LTE CATM1 NBIoT Region
ML865G1-WW 850, 900, 1800,
1900
B1, B2, B3, B4,
B5, B8, B12,
B13, B18, B19,
B20, B25, B26,
B27, B28, B66,
B85
B1, B2, B3, B4,
B5, B8, B12,
B13, B18, B19,
B20, B25, B26,
B28, B66, B71,
B85
Worldwide
Refer to “RF Section” for details information about frequencies.
NOTE:
Cellular technologies and frequency bands that are enabled may
vary based on firmware version and firmware configuration used.
