ML865G1 HW Design Guide
1VV0301632 Rev. 4 Page 17 of 86 2020-09-23
CAT NB2 / Band85 -115.9 -
* 3GPP TS 36.521-1 Release 15
Mechanical Specifications
2.7.1. Dimensions
The overall dimensions of ML865G1-WW are:
• Length: 24.0 mm
• Width: 24.0 mm
• Thickness: 2.6 mm
2.7.2. Weight
The nominal weight of the ML865G1-WW is 2 grams.
Temperature Range
Note
Operating Temperature
Range
–40°C to +85°C
The module is fully functional (*) and
compliant according to regulatory
standards.
Storage Temperature
Range
–40°C to +105°C
The module is not powered and not
connected to power supply
(*) Functional: if applicable, the module is able to make and receive voice calls, data calls,
send and receive SMS and data traffic.
