ML865G1 HW Design Guide
1VV0301632 Rev. 4 Page 25 of 86 2020-09-23
NOTE:
For PTCRB approval on the final products the power supply is
required to be within the “Normal Operating Voltage Range”.
Power Consumption
4.2.1. Idle mode
Mode
Measure
(Typical)
Mode
Description
IDLE
MODE
CATM
(mA)
NBIoT
(mA)
2G
(mA)
AT+CFUN=1 9.5 9.2 9.0
Normal mode: full functionality of the
module
AT+CFUN=4 7.5
Disabled TX and RX; module is not
registered on the network
AT+CFUN=5
1.20 0.95 -
Paging cycle #256 frames (2.56s DRx
cycle)
0.60 0.60 -
81.92s eDRx cycle length (PTW=2.56s,
DRX=1.28s)
0.18
1
0.18
1
-
327.68s eDRx cycle length (PTW=2.56s,
DRX=1.28s)
0.10
1
0.10
1
-
655.36s eDRx cycle length (PTW=2.56s,
DRX=1.28s)
0.05
1
0.05
1
-
1310.72s eDRx cycle length (PTW=2.56s,
DRX=1.28s)
0.03
1
0.03
1
-
2621.44s eDRx cycle length (PTW=2.56s,
DRX=1.28s)
- - 0.90 Paging Multiframe 9
