ML865G1 HW Design Guide

1VV0301632 Rev. 4 Page 70 of 86 2020-09-23

9. MECHANICAL DESIGN

Drawing

NOTE:

Dimensions in mm.

General Tolerance ±0.1, Angular Tolerance ±1°, The tolerance is not

cumulative.
