ML865G1 HW Design Guide
1VV0301632 Rev. 4 Page 56 of 86 2020-09-23
Item Min Typical Max Unit
Input Voltage range 0 - 1.8 Volt
AD conversion - - 10 bits
Input Resistance 1 - - Mohm
Input Capacitance - 1 - pF
5.11.1. Using ADC Converter
Available in a next document revision.
Forced USB boot
In some case of firmware upgrade FORCED_USB_BOOT pin must be set to 1.8V during
poweron of ML865G1.
The input current is very low so 10K resistor to 1.8V supply can be used to keep this pin in
HI state.
FORCED_USB_BOOT pin must be connected only during firmware upgrade operation and
normally it has to be left open.
FORCED_USB_BOOT pin must be available in the user application circuit throught test
points for easy connection of 10K resistor and 1.8V supply.
