ML865G1 HW Design Guide
1VV0301632 Rev. 4 Page 26 of 86 2020-09-23
1
PSM in between eDRX
*reference signal @-130 dbm with static scenario
NOTE:
The reported LTE CAT M1 and LTE CAT NB1 values are an average
among all the product variants and bands for each network wireless
technology.
The support of specific network wireless technology depends on
product variant configuration.
PSM
MODE
Typical (mA)
AT+CPS
MS=1
3uA
No current source or sink by any connected
pin
Mode
Measure*
(Typical)
Mode Description
GPS
(mA)
Active State
(GNSS ON,
CFUN=4)
Acquisition 69.3 GPS+GLO, DPO off
Navigation
22 GPS+GLO, DPO on DWELL=280ms
55.9 GPS+GLO, DPO off
Active State
(GNSS ON,
CFUN=5 eDRX)
Acquisition 68.5 GPS+GLO, DPO off
Navigation
15.7 GPS+GLO, DPO on DWELL=280ms
54 GPS+GLO, DPO off
