Page 1-1
1
Description and Specifications
Introduction NET-PATH is available in several configurations. All standard models include:
• 8 serial ports, 1 NIC
• 1 56K BPS modem
• 16 contact sensors
• 2 output relays (available through RJ45 connector)
• 1 DC voltage sensor (requires optional external cable)
• 2 temperature sensors, one internal, one external (external sensor requires addi-
tional equipment)
•integrated UPS
• LCD display panel
• audible alarm
• basic event processing software including Python script execution
Configuration variables include four RS232 ports, eight contact sensors, and SNMP
Segment Management software, AC or DC input power.
Determining the
NET-PATH
Model
The serial number and model information is on a label attached to the bottom of the
unit.
NET-PATH
Model Structure
Figure 1-1 shows how to use the model number to determine basic hardware
functions. The figure shows model 43308-U2OSA, which includes four serial ports, a
North American modem, 20 MB of memory, and networking with management for
twenty network elements.
