Description and Specifications
Page 1-4
Hardware
Specifications
Modem
• 56K internal modem
• V.42 MNP (2-4) error correction
• V.42 BIS MNP5 data compression
• Group 3 Fax
Microprocessor
• Motorola 860T
• 32 MB FLASH Memory
•128 MB S DRAM
Dimensions
• Height 1.75 inches
• Width 17 inches (fits 19” rack)
• Depth10.5 inches
Weight
• Approximately 12 lb.
Environmental Requirements
•50° to 110° F operating temperature (10° to 43° C)
•20°
to 140° F non-operating temperature (-29° to 60° C)
• 20% to 80% relative humidity, nonconducting
Power Requirements
*The DC input range is -36 V to -72 V; -48 VDC nominal.
Host System Interface
Depending on the options you choose, the NET-PATH can have four to eight EIA RS-
232-C serial ports. Connectors for the NET-PATH (labeled Host 1 through Host n) are
configured as Data Terminal Equipment (DTE), using RJ45 male connectors.
Transmission rates can vary from 110 BPS to up to 115 KBPS.
Telephone Line Interface
The telephone connection is a modular RJ11C interface. Pulse dialing or tone
signaling (DTMF) is a software option.
Input power Voltage Current Watts BTU/hr
AC 110 volts 180 mA 19.80 67.56
DC* 48 volts 250 mA 12.00 40.95
