NET-PATH Installation and Operation Guide
Page 2-15
Power The NET-PATH comes with a standard AC power cord. The internal power supply is
rated 110/220 V, 50/60 Hz. In international applications, the external power cord must
be replaced with one that supports the local wiring configuration.
Reset Button The recessed Reset button located on the back of the NET-PATH resets the
microprocessor in the NET-PATH and initiates a warm boot. Both warm and cold
boots result in the loss of active event data. Data stored in flash memory is retained,
while the date stored in RAM is lost.
Battery The NET-PATH contains a 12-volt, rechargeable battery. This battery does not require
field maintenance. This battery life expectancy is one to three years. The NET-PATH
reports battery conditions and capacity. Batteries can be replaced in the field.
The UPS battery ships from the factory fully charged. The following graph shows the
battery discharge characteristics when the unit is stored for an extended period.
Extended storage does not affect the battery’s ability to recharge to full capacity when
the unit is operational.
Figure 2-20 UPS Battery Self-Discharge Characteristics
Warning Use care when working with your battery. Do not
touch the battery with conducting materials, such as rings,
bracelets, keys, and tools. Do not open or mutilate the
battery. Do not dispose of the battery in fire.
You risk explosion if you replace a battery with an incorrect
type. Dispose of used batteries in accordance the
manufacturer’s instructions.
