Installation
Page 2-8
Contact Sensor
Strap Options
The top cover must be removed to configure contact sensor strap options. NET-PATH
units are shipped with the contacts set to RS232C mode, which is used for the
majority of sensing applications. If the monitored device only supports RS423A
output then select which contact(s) you want to use and strap them for RS423A input.
The following table provides the connector numbers for each sensor.
Table 2-2: Contact Sensor Strap Options
Sensor
Number
Sensor
Option Strap1
Sensor Option
Strap 2
RS232C
Input
RS423A
Input
1 J28 J36 Pins 1 & 2 Pins 2 & 3
2 J29 J37 Pins 1 & 2 Pins 2 & 3
3 J30 J38 Pins 1 & 2 Pins 2 & 3
4 J31 J39 Pins 1 & 2 Pins 2 & 3
5 J32 J40 Pins 1 & 2 Pins 2 & 3
6 J33 J41 Pins 1 & 2 Pins 2 & 3
7 J34 J42 Pins 1 & 2 Pins 2 & 3
8 J35 J43 Pins 1 & 2 Pins 2 & 3
9 J44 J52 Pins 1 & 2 Pins 2 & 3
10 J45 J53 Pins 1 & 2 Pins 2 & 3
11 J46 J54 Pins 1 & 2 Pins 2 & 3
12 J47 J55 Pins 1 & 2 Pins 2 & 3
13 J48 J56 Pins 1 & 2 Pins 2 & 3
14 J49 J57 Pins 1 & 2 Pins 2 & 3
15 J50 J58 Pins 1 & 2 Pins 2 & 3
16 J51 J59 Pins 1 & 2 Pins 2 & 3
