Portable Wireless AP/Router
11g mode Allow the 11g/11n-compliant client device
to connect with the AP at the maximum
speed of 54Mbps.
11b/g mode: Allow the 11b/g-compliant client device to
connect with the AP with auto-negotiation
speed, and 11n wireless client to connect
the device with 11g speed.
11b/g/n mode: Allow the 11b/g/n-compliant client
device to connect with the AP with
auto-negotiation speed.
² SSID SSID (Service Set Identifier) is the unique
name of the wireless network. This device has two
SSID and the main SSID is necessary.
² Broadcast (SSID): Select “Enable” to enable the
device's SSID to be visible by wireless clients. The
default is enabled. If you disable it, the clients must
know the SSID to communicate.
² BSSID Basic Service Set Identifier of wireless
network. In IEEE802.11, BSSID is the MAC address
of wireless access point.
² Standard Channel Specify the effective channel
