Tera 2I386EW - Page 86

81
IO=3E8h; IRQ=3,4
IO=3F8h; IRQ=3,4
Serial Port 3 Base IO Address / Interrupt
Use this item to select an optimal setting for super IO device.
The optional settings are:
IO=3E8h; IRQ=10 (default)
IO=2F8h; IRQ=3,4,5,6,7,10,11
IO=2E8h; IRQ=3,4,5,6,7,10,11
IO=3F8h; IRQ=3,4,5,6,7,10,11
IO=4F8h; IRQ=3,4,5,6,7,10,11
IO=4E8h; IRQ=3,4,5,6,7,10,11
Serial Port 4 Base IO Address / Interrupt
Use this item to select an optimal setting for super IO device.
The optional settings are:
IO=2E8h; IRQ=10(default)
IO=2F8h; IRQ=3,4,5,6,7,10,11
IO=3F8h; IRQ=3,4,5,6,7,10,11
IO=3E8h; IRQ=3,4,5,6,7,10,11
IO=4F8h; IRQ=3,4,5,6,7,10,11
IO=4E8h; IRQ=3,4,5,6,7,10,11
Serial Mode
RS232 driver(default) : When hardware select to RS232 or RS422 mode, please enter to RS232 driver.
RS485 driver : When hardware select to RS485 mode, please enter to RS485 driver. It is the auto fl ow
function for RS485.
Sharing Mode
This item is OS serial port with sharing mode issue.
If use Linux OS this item should be ISA mode
If use Windows OS this item should be PCI mode
Note: Windows don’t set to ISA mode.
