Terex MAC 25 - Page 41

MAC-25 OFFSET HEAD TOP POSITION LOAD CHART - 10 DE
G
LMI DUT
Y
204
COUNTERWEIGHT ON REAR OF CRANE - SPRING LOCKOUTS ENGAGED
S.W.L. ARE BASED ON 66.7% STABILITY & STRENGTH
S.W.L IN KILOGRAMS FOR SLEW ANGLES OF 10 DEGREES OR LESS EITHER
- S.W.L. ABOVE BOLD RED LINE ARE STRUCTURAL
SIDE OF STRAIGHT AHEAD (INDICATED BY GREEN LED ON DASH).
S.W.L. ARE BASED ON FIRM LEVEL GROUND (1% SLOPE (0.6 DEG) AS PER AS1418.5)
BOOM ANGLE - UNDEFLECTED (REF.)
WITH TYRES INFLATED AS PER NOTES
NOTE :
VALUES IN BRACKETS ( ) ARE ACTUAL RADIUS AT ZERO DEG. BOOM ANGLE.
LIFT & CARRY - THE S.W.L. SHALL BE CARRIED WITH THE MINIMUM BOOM LENGTH & AS
CLOSE TO THE GROUND AS POSSIBLE AT SPEEDS NOT IN EXCESS OF 0.4 M/SEC (1.44 KM/HR)
Radius BOOM PIVOT TO EDGE OF SHEAVE - THIRD BOOM RETRACTED THIRD BOOM EXTENDING
in (metres) (metres)
Metres 6.82 7.00 7.50 8.00 8.50 9.00 9.50 10.00 10.50 11.00 11.50 12.00 12.50 13.00 13.50 14.00 14.50 15.02 15.50 16.00 16.50 17.00 17.50 18.00 18.50 19.12
1.4
8400 8400 8400 8400 8400 8400 8400
52 53 56 58 60 62 64
2.0
8400 8400 8400 8400 8400 8400 8400 8400 8400 8400
WINCH S.W.L.
45 47 50 53 56 58 60 61 63 64 SINGLE PART 4200
2.5
8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 TWO PARTS 8400
39 41 45 49 52 54 56 58 60 61 63 64
3.0
8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400
32 34 40 44 47 50 53 55 57 58 60 61 63 64 65
3.5
8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400
24 27 33 38 42 46 49 51 53 55 57 59 60 61 62 63 64
4.0
8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400 8400
(4.1) 16 26 32 37 41 45 47 50 52 54 56 57 59 60 61 62 63 64
5.0
8400 8400 8400 8400 8400 8400 8400 8400 8350 8350 8300 8300 8300 8250 8250 8250 8250 8250 8300 8300 8200 8050 7950
(4.3) (4.8) 15 24 30 35 39 42 45 48 50 52 53 55 56 58 59 60 61 62 63 64 65
6.0
7950 7100 6800 6800 6800 6750 6750 6700 6700 6700 6700 6650 6650 6650 6600 6650 6700 6750 6750 6800 6800 6850 6300
(5.3) (5.8) 14 23 29 34 37 40 43 46 48 50 51 53 54 56 57 58 59 60 61 62 63
7.0
6400 5800 5600 5600 5550 5550 5550 5550 5500 5500 5500 5500 5450 5500 5550 5550 5600 5650 5650 5700 5700
(6.3) (6.8) 14 22 28 32 36 39 41 44 46 48 50 51 53 54 55 56 57 58 59
8.0
5300 4850 4700 4700 4650 4650 4650 4650 4650 4600 4600 4650 4700 4700 4750 4750 4800 4800 4850
(7.3) (7.8) 13 21 27 31 34 37 40 42 44 46 48 49 51 52 53 55 56
9.0
4450 4100 4000 4000 3950 3950 3950 3950 3950 3950 4000 4050 4050 4100 4100 4150 4150
(8.3) (8.8) 12 20 25 30 33 36 39 41 43 45 46 48 49 51 52
10
3800 3500 3400 3400 3400 3400 3400 3450 3450 3500 3500 3550 3550 3600 3650
(9.3) (9.8) 12 19 25 29 32 35 37 40 42 43 45 47 48
11
3250 3050 2950 2950 2950 3000 3000 3050 3100 3100 3150 3150 3200
(10.3) (10.8) 12 19 24 28 31 34 36 38 40 42 44
12
NOTE : WEIGHT OF HOOKS, BLOCKS & OTHER 2850 2650 2550 2600 2650 2700 2700 2750 2750 2800 2800
LOAD HANDLING DEVICES SHALL BE ADDED (11.3) (11.8) 12 18 23 27 30 33 35 37 40
13
TO THE WEIGHT OF THE LOAD 2450 2350 2350 2350 2400 2400 2450 2450 2500
(12.3) (12.8) 11 18 22 26 29 32 35
14
2250 2150 2100 2150 2150 2200 2200
(13.3) (13.8) 11 17 22 25 29
15
2050 1950 1950 1950 2000
(14.3) (14.8) 10 17 22
16.45
1850 1800 1700
(15.3) (15.8) (16.5)
39/66 MXC1347B COUNTERWEIGHT - REAR MAC 25 OFFSET HEAD TOP POSITION - 10 DEG
