2-15
Safety
Installation of Bracket for Mirror H
The bracket provided for the mounting of mirror H is supplied as a loose item, and must be installed by the customer
in the position defined by the illustration below.
Installation of Bracket for Mirror G
The bracket provided for the mounting of mirror G is supplied as a loose item, and must be installed by the customer
in the position defined by the illustration below.
2073
170
50
MIRROR
ATTACHMENT
POSITION
TRUE VIEW ON 'A'
A
Ref.
LHS HANDRAIL
Ref. CAB
NOT TO SCALE
2074
Ref. RADIATOR GUARD
