7
PREPARATION FOR INSTALLATION
PRELIMINARY INFORMATION
CL115D
Nominal output power 15000 VA / 10500 Watt
Operating temperature 0 – 40 C
Non operating temper. -10 to + 50 C
Max.relative humidity 90% (non-condensing) during operation
Max.installation altitude 2000 m at nominal power rating
Dimensions (WxDxH) 215 x 775 x 585 mm
Weight (kgs) 41 (without batteries)
Protection level IP20
Cables inlet from rear side (screw terminals)
Communication RS232 standard
LCD panel and mimic Available - Standard
Software management Available - Standard
Dry contact outputs Available - Standard
REPO input Available – Standard ( NO or NC programmable)
ELECTROMAGNETIC COMPATIBILITY
This uninterruptible power supply (UPS) conforms to the class C2 specifications (in accordance with the
provisions laid down by the EN62040-2 standard: UPS – EMC requirement). In the home environment, it may
cause radio interference. The user may have to take supplementary measures.
This product is designed for professional use in industrial and commercial environments. Connections to the
RS232 connectors should be made with the cables provided or, in any case, with shielded cables less than
three meters long.
INSTALLATION ENVIRONMENT
When choosing the site in which to install the UPS, the following points should be taken into consideration:
• Avoid dusty environments
• Check that the floor is level and capable of withstanding the weight of the UPS
• Avoid cramped environments that could impede the normal maintenance activities
• The relative humidity should not exceed 90%, non-condensing.
• Check that the ambient temperature, with the UPS running, remains between 0 and 40 C
• Avoid installing the equipment in places exposed to the direct sunlight and hot air.
REMOVING THE UPS FROM PALLET
The UPS is packed and enclosed in a structural cardboard carton to protect it from damage.
1. Inspect for damage that may have occurred during the shipment If any damage is noted, call the
shipper immediately and retain the shipping carton and the UPS.
2. Carefully open the carton and take the UPS out.
Retain the carton and packing material for possible future use
PRELIMINARY CHECK OF CONTENTS
Having opened the package, start by checking the contents
-User manual
-CC05 coded serial RS232 connection cable
-UPS manager software and user manual CD-rom
-Guarantee document
