18
MEASURES MENU _________________________________________________________
LOAD:025% 05.0A
Use Up and Down buttons to move on submenu
OUT.:230V 50.0Hz
BYP.:230V 50.2Hz (option)
LOAD CF.: 1.4
INP.:240V 49.9Hz
I/P CURR.: 18.5 A
BATT:257V +0.50A
BAT. TIME: - - - mn
TEMP: +025 C
<ENT>EXIT
From this menu users can see all measured parameters of the UPS. The submenu items are listed as follows
by order of appearance.
LOAD:025% 05.0A
Output load percentage and output load current in amperes
OUT.:230V 50.0Hz
Output AC voltage and frequency in Hertz
BYP.:230V 50.2Hz
Bypass AC input voltage and bypass input frequency in Hertz
(This submenu is available only if split-bypass option is selected)
LOAD CF.: 1.4
Load crest factor measurement. For linear loads the crest factor is 1.4 ,for nonlinear loads the value is bigger
then 1.4. The UPS can supply bigger peak output current to the load according to RMS current. The maximum
crest factor is 3.
INP.:240V 49.9Hz
Rectifier AC input voltage and rectifier input frequency in Hertz
I/P CURR.: 18.5 A
UPS rectifier input current in amperes
BATT:257V +0.50A
Total battery DC voltage in volts and battery charge current in amperes.
BAT. TIME: - - - mn
Remaining battery time during battery operation in terms of minutes.
TEMP: +025 C
Cabinet inside temperature
<ENT>EXIT
If the user presses ENTER button, exits from measures menu.
