COMMAND MENU __________________________________________________________
From this menu user can apply immediate commands to the UPS.
SOUND.: ON
Use Up and Down buttons to move on submenu
<ENT> BYPASS
<ENT>CANCEL SHUT
<ENT>LAMP TEST
<ENT>EXIT
SOUND: ON or OFF
Each pressing to ENTER button will change the alarm buzzer enable(on) or disable(off) status.
<ENT> BYPASS
If the user presses the ENTER button, UPS transfers the load to bypass. During bypass <ENTER>START
message is shown instead, meaning that ENTER button will start the inverter and transfers the load to inverter
again.
<ENT>CANCEL SHUT
If shutdown process is active ,ENTER button cancels the shutdown. The shutdown process is
controlled via RS232 port.
<ENT>LAMP TEST
ENTER button starts panel lamps test function. At the same time during test , buzzer beeps.
<ENT>EXIT
If the user presses ENTER button, exits from command menu..
ALARM CODES
The following table shows the alarm and warning messages of the UPS. If an alarm occurs, inverter stops and
the load is transferred to bypass. If a warning message occurs, inverter continues its operation.
Message class
A7 BATTERY LOW Warning
A7 BAT.LOW SHUT. Alarm
A8 OUTPUT HIGH Alarm
A9 OVLD.SHUTDOWN Alarm
A9 OVERLOAD Warning
A10 LINE FAILURE Warning
A11 OVERTEMP. Warning
A12 OVERCURRENT Alarm
A13 OUTPUT LOW Alarm
A14 BATTERY HIGH Alarm
A16 BYP INP.BAD Warning
A17 BAT.CB OPEN Warning
A19 BATT.FAULT Warning
A20 BOOST CHARGE Warning
A22 OUTPUT OFF Warning
A23 SERVICE TIME Warning
A42 BATTERY TEST Warning
A48 STATIC BYP Warning
