5.9 External Capacitors
To improve module performance, decoupling capacitors are required to suppress the switching noise generated
by high frequency and to stabilize the supply voltage. A decoupling capacitor is most effective when it is close to
the device, because this minimizes the inductance of the circuit board wiring and interconnects.
5.9.1 Voltage Decoupling Capacitors
Table 5-13 summarizes the Core voltage decoupling characteristics.
5.9.1.1 Core Voltage Decoupling Capacitors
To improve module performance, decoupling capacitors are required to suppress high-frequency switching noise
and to stabilize the supply voltage. A decoupling capacitor is most effective when located close to the AM335x
device, because this minimizes the inductance of the circuit board wiring and interconnects.
Table 5-13. Core Voltage Decoupling Characteristics
PARAMETER TYP UNIT
C
VDD_CORE
(1)
10.08 μF
C
VDD_MPU
(2)(3)
10.05 μF
(1) The typical value corresponds to 1 cap of 10 μF and 8 caps of 10 nF.
(2) Not available on the ZCE package. VDD_MPU is merged with VDD_CORE on the ZCE package.
(3) The typical value corresponds to 1 cap of 10 μF and 5 caps of 10 nF.
5.9.1.2 IO and Analog Voltage Decoupling Capacitors
Table 5-14 summarizes the power-supply decoupling capacitor recommendations.
Table 5-14. Power-Supply Decoupling Capacitor Characteristics
PARAMETER TYP UNIT
C
VDDA_ADC
10 nF
C
VDDA1P8V_USB0
10 nF
C
CVDDA3P3V_USB0
10 nF
C
VDDA1P8V_USB1
(1)
10 nF
C
VDDA3P3V_USB1
(1)
10 nF
C
VDDS
(2)
10.04 μF
C
VDDS_DDR
(3)
C
VDDS_OSC
10 nF
C
VDDS_PLL_DDR
10 nF
C
VDDS_PLL_CORE_LCD
10 nF
C
VDDS_SRAM_CORE_BG
(4)
10.01 μF
C
VDDS_SRAM_MPU_BB
(5)
10.01 μF
C
VDDS_PLL_MPU
10 nF
C
VDDS_RTC
10 nF
C
VDDSHV1
(6)
10.02 μF
C
VDDSHV2
(1)(6)
10.02 μF
C
VDDSHV3
(1)(6)
10.02 μF
C
VDDSHV4
(6)
10.02 μF
C
VDDSHV5
(6)
10.02 μF
C
VDDSHV6
(7)
10.06 μF
