Texas Instruments AM335x Sitara User Manual

AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015 www.ti.com
4 Terminal Configuration and Functions
4.1 Pin Diagrams
NOTE
The terms 'ball', 'pin', and 'terminal' are used interchangeably throughout the document. An
attempt is made to use 'ball' only when referring to the physical package.
4.1.1 ZCE Package Pin Maps (Top View)
The pin maps below show the pin assignments on the ZCE package in three sections (left, middle, and
right).
