AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
5.6 Power Consumption Summary
Table 5-10 summarizes the power consumption at the AM335x power terminals.
Table 5-10. Maximum Current Ratings at AM335x Power Terminals
(1)
SUPPLY NAME DESCRIPTION MAX UNIT
Maximum current rating for the core domain; OPP100 400 mA
VDD_CORE
(2)
Maximum current rating for the core domain; OPP50 250 mA
Maximum current rating for the MPU domain; Nitro at 1 GHz 1000 mA
Maximum current rating for the MPU domain; Turbo at 800 MHz 800 mA
at 720 MHz 720
Maximum current rating for the MPU domain; OPP120 at 720 MHz 720 mA
at 600 MHz 600
VDD_MPU
(2)
Maximum current rating for the MPU domain; OPP100 at 600 MHz 600 mA
at 500 MHz 500
at 300 MHz 380 mA
at 275 MHz 350
Maximum current rating for the MPU domain; OPP50 at 300 MHz 330 mA
at 275 MHz 300
CAP_VDD_RTC
(3)
Maximum current rating for RTC domain input and LDO output 2 mA
VDDS_RTC Maximum current rating for the RTC domain 5 mA
VDDS_DDR Maximum current rating for DDR IO domain 250 mA
VDDS Maximum current rating for all dual-voltage IO domains 50 mA
VDDS_SRAM_CORE_BG Maximum current rating for core SRAM LDOs 10 mA
VDDS_SRAM_MPU_BB Maximum current rating for MPU SRAM LDOs 10 mA
VDDS_PLL_DDR Maximum current rating for the DPLL DDR 10 mA
VDDS_PLL_CORE_LCD Maximum current rating for the DPLL Core and LCD 20 mA
VDDS_PLL_MPU Maximum current rating for the DPLL MPU 10 mA
VDDS_OSC Maximum current rating for the system oscillator IOs 5 mA
VDDA1P8V_USB0 Maximum current rating for USBPHY 1.8 V 25 mA
VDDA1P8V_USB1
(4)
Maximum current rating for USBPHY 1.8 V 25 mA
VDDA3P3V_USB0 Maximum current rating for USBPHY 3.3 V 40 mA
VDDA3P3V_USB1
(4)
Maximum current rating for USBPHY 3.3 V 40 mA
VDDA_ADC Maximum current rating for ADC 10 mA
VDDSHV1
(5)
Maximum current rating for dual-voltage IO domain 50 mA
VDDSHV2
(4)
Maximum current rating for dual-voltage IO domain 50 mA
VDDSHV3
(4)
Maximum current rating for dual-voltage IO domain 50 mA
VDDSHV4 Maximum current rating for dual-voltage IO domain 50 mA
VDDSHV5 Maximum current rating for dual-voltage IO domain 50 mA
VDDSHV6 Maximum current rating for dual-voltage IO domain 100 mA
(1) Current ratings specified in this table are worst-case estimates. Actual application power supply estimates could be lower. For more
information, see the AM335x Power Consumption Summary application report (SPRABN5).
(2) VDD_MPU is merged with VDD_CORE and is not available separately on the ZCE package. The maximum current rating for
VDD_CORE on the ZCE package is the sum of VDD_CORE and VDD_MPU shown in this table.
(3) This supply is sourced from an internal LDO when RTC_KALDO_ENn is low. If RTC_KALDO_ENn is high, this supply must be sourced
from an external power supply.
(4) Not available on the ZCE package.
(5) VDDSHV1 and VDDSHV2 are merged in the ZCE package. The maximum current rating for VDDSHV1 on the ZCE package is the sum
of VDDSHV1 and VDDSHV2 shown in this table.
Copyright © 2011–2015, Texas Instruments Incorporated Specifications 87
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
