5.5 Recommended Operating Conditions
over junction temperature range (unless otherwise noted)
SUPPLY NAME DESCRIPTION MIN NOM MAX UNIT
Supply voltage range for core
1.056 1.100 1.144
domain; OPP100
VDD_CORE
(1)
V
Supply voltage range for core
0.912 0.950 0.988
domain; OPP50
Supply voltage range for MPU
1.272 1.325 1.378
domain, Nitro
Supply voltage range for MPU
1.210 1.260 1.326
domain; Turbo
Supply voltage range for MPU
VDD_MPU
(1)(2)
1.152 1.200 1.248 V
domain; OPP120
Supply voltage range for MPU
1.056 1.100 1.144
domain; OPP100
Supply voltage range for MPU
0.912 0.950 0.988
domain; OPP50
Supply voltage range for RTC
CAP_VDD_RTC
(3)
0.900 1.100 1.250 V
domain input
Supply voltage range for RTC
VDDS_RTC 1.710 1.800 1.890 V
domain
Supply voltage range for DDR IO
1.710 1.800 1.890
domain (DDR2)
Supply voltage range for DDR IO
VDDS_DDR 1.425 1.500 1.575 V
domain (DDR3)
Supply voltage range for DDR IO
1.283 1.350 1.418
domain (DDR3L)
Supply voltage range for all dual-
VDDS
(4)
1.710 1.800 1.890 V
voltage IO domains
Supply voltage range for Core
VDDS_SRAM_CORE_BG 1.710 1.800 1.890 V
SRAM LDOs, analog
Supply voltage range for MPU
VDDS_SRAM_MPU_BB 1.710 1.800 1.890 V
SRAM LDOs, analog
Supply voltage range for DPLL
VDDS_PLL_DDR
(5)
1.710 1.800 1.890 V
DDR, analog
Supply voltage range for DPLL
VDDS_PLL_CORE_LCD
(5)
1.710 1.800 1.890 V
CORE and LCD, analog
Supply voltage range for DPLL
VDDS_PLL_MPU
(5)
1.710 1.800 1.890 V
MPU, analog
Supply voltage range for system
VDDS_OSC 1.710 1.800 1.890 V
oscillator IO's, analog
Supply voltage range for
VDDA1P8V_USB0
(5)
USBPHY and PER DPLL, 1.710 1.800 1.890 V
analog, 1.8 V
Supply voltage range for USB
VDDA1P8V_USB1
(6)
1.710 1.800 1.890 V
PHY, analog, 1.8 V
Supply voltage range for USB
VDDA3P3V_USB0 3.135 3.300 3.465 V
PHY, analog, 3.3 V
Supply voltage range for USB
VDDA3P3V_USB1
(6)
3.135 3.300 3.465 V
PHY, analog, 3.3 V
Supply voltage range for ADC,
VDDA_ADC 1.710 1.800 1.890 V
analog
Supply voltage range for dual-
VDDSHV1 voltage IO domain (1.8-V 1.710 1.800 1.890 V
operation)
Supply voltage range for dual-
VDDSHV2
(6)
voltage IO domain (1.8-V 1.710 1.800 1.890 V
operation)
