0
Supply value
t
slew rate < 1E + 5 V/s
slew > (supply value) / (1E + 5V/s)
supply value * 10 µs
AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com SPRS717H –OCTOBER 2011–REVISED MAY 2015
6 Power and Clocking
6.1 Power Supplies
6.1.1 Power Supply Slew Rate Requirement
To maintain the safe operating range of the internal ESD protection devices, it is recommended to limit the
maximum slew rate for powering on the supplies to be less than 1.0E +5 V/s. For instance, as shown in
Figure 6-1, TI recommends to have the supply ramp slew for a 1.8-V supply be greater than 18 µs.
Figure 6-1. Power Supply Slew and Slew Rate
Copyright © 2011–2015, Texas Instruments Incorporated Power and Clocking 99
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
