Texas Instruments AM335x Sitara User Manual

AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015 www.ti.com
Table 5-8. Valid Combinations of VDD_CORE and
VDD_MPU OPPs for ZCZ Package With Device
Revision Code "A" or Newer
VDD_CORE VDD_MPU
OPP50 OPP50
OPP50 OPP100
OPP100 OPP50
OPP100 OPP100
OPP100 OPP120
OPP100 Turbo
OPP100 Nitro
Table 5-9. VDD_CORE OPPs for ZCE Package
with Device Revision Code "A" or Newer
(1)
VDD_CORE VDD_MPU
(2)
OPP DDR3,
ARM (A8) DDR2
(3)
mDDR
(3)
L3 and L4
Rev "A" or DDR3L
(3)
MIN NOM MAX
newer
OPP100 1.056 V 1.100 V 1.144 V 600 MHz 400 MHz 266 MHz 200 MHz 200 and 100
MHz
OPP100 1.056 V 1.100 V 1.144 V 300 MHz 400 MHz 266 MHz 200 MHz 200 and 100
MHz
OPP50 0.912 V 0.950 V 0.988 V 300 MHz — 125 MHz 90 MHz 100 and 50
MHz
(1) Frequencies in this table indicate maximum performance for a given OPP condition.
(2) VDD_MPU is merged with VDD_CORE on the ZCE package.
(3) This parameter represents the maximum memory clock frequency. Since data is transferred on both edges of the clock, double-data rate
(DDR), the maximum data rate is two times the maximum memory clock frequency defined in this table.
84 Specifications Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
