AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
Table 5-4. Valid Combinations of VDD_CORE and
VDD_MPU OPPs for ZCZ Package with Device Revision
Code "Blank"
VDD_CORE VDD_MPU
OPP50 OPP100
OPP100 OPP100
OPP100 OPP120
OPP100 Turbo
Table 5-5. VDD_CORE OPPs for ZCE Package
with Device Revision Code "Blank"
(1)
VDD_CORE VDD_MPU
(2)
OPP DDR3,
ARM (A8) DDR2
(3)
mDDR
(3)
L3 and L4
Device Rev. DDR3L
(3)
MIN NOM MAX
"Blank"
OPP100 1.056 V 1.100 V 1.144 V 500 MHz 400 MHz 266 MHz 200 MHz 200 and 100
MHz
OPP100 1.056 V 1.100 V 1.144 V 275 MHz 400 MHz 266 MHz 200 MHz 200 and 100
MHz
(1) Frequencies in this table indicate maximum performance for a given OPP condition.
(2) VDD_MPU is merged with VDD_CORE on the ZCE package.
(3) This parameter represents the maximum memory clock frequency. Since data is transferred on both edges of the clock, double-data rate
(DDR), the maximum data rate is two times the maximum memory clock frequency defined in this table.
Table 5-6. VDD_CORE OPPs for ZCZ Package
with Device Revision Code "A" or Newer
(1)
VDD_CORE VDD_CORE
OPP DDR3,
DDR2
(2)
mDDR
(2)
L3 and L4
Rev "A" or DDR3L
(2)
MIN NOM MAX
Newer
OPP100 1.056 V 1.100 V 1.144 V 400 MHz 266 MHz 200 MHz 200 and 100
MHz
OPP50 0.912 V 0.950 V 0.988 V — 125 MHz 90 MHz 100 and 50
MHz
(1) Frequencies in this table indicate maximum performance for a given OPP condition.
(2) This parameter represents the maximum memory clock frequency. Since data is transferred on both edges of the clock, double-data rate
(DDR), the maximum data rate is two times the maximum memory clock frequency defined in this table.
Table 5-7. VDD_MPU OPPs for ZCZ Package
with Device Revision Code "A" or Newer
(1)
VDD_MPU
VDD_MPU OPP
ARM (A8)
Rev "A" or Newer
MIN NOM MAX
Nitro 1.272 V 1.325 V 1.378 V 1 GHz
Turbo 1.210 V 1.260 V 1.326 V 800 MHz
OPP120 1.152 V 1.200 V 1.248 V 720 MHz
OPP100
(2)
1.056 V 1.100 V 1.144 V 600 MHz
OPP100
(3)
1.056 V 1.100 V 1.144 V 300 MHz
OPP50 0.912 V 0.950 V 0.988 V 300 MHz
(1) Frequencies in this table indicate maximum performance for a given OPP condition.
(2) Applies to all orderable AM335__ZCZ_60 (600 MHz speed grade) or higher devices.
(3) Applies to all orderable AM335__ZCZ_30 (300 MHz speed grade) devices.
Copyright © 2011–2015, Texas Instruments Incorporated Specifications 83
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
