Pin map section location
AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
ZCE Pin Map [Section Left - Top View]
A B C D E F
19 VSS I2C0_SCL UART1_TXD UART1_RTSn UART0_RXD UART0_CTSn
18 SPI0_SCLK SPI0_D0 I2C0_SDA UART1_RXD ECAP0_IN_PWM0_OUT UART0_RTSn
17 SPI0_CS0 SPI0_D1 EXTINTn XXXX UART1_CTSn UART0_TXD
16 WARMRSTn SPI0_CS1 XXXX XXXX XXXX VDDS
15 EMU0 XDMA_EVENT_INTR1 XDMA_EVENT_INTR0 XXXX PWRONRSTn XXXX
14 TDO TCK TMS EMU1 XXXX VDDSHV6
13 TRSTn TDI CAP_VBB_MPU CAP_VDD_SRAM_MPU VDDSHV6 VSS
12 AIN7 AIN5 VDDS_SRAM_MPU_BB VDDS VDDSHV6 VSS
11 AIN1 AIN3 XXXX XXXX VDDSHV6 VDD_CORE
10 AIN6 CAP_VDD_SRAM_CORE VDDS_SRAM_CORE_BG VSS VSS XXXX
9 VREFP VREFN XXXX XXXX VSS VDD_CORE
8 AIN2 AIN0 AIN4 VSSA_ADC VSS VSS
7 RTC_KALDO_ENn RTC_PWRONRSTn PMIC_POWER_EN VDDA_ADC VSS VSS
6 RTC_XTALIN RESERVED VDDS_RTC CAP_VDD_RTC XXXX VSS
5 RTC_XTALOUT EXT_WAKEUP VDDS_PLL_DDR XXXX DDR_A4 XXXX
4 DDR_WEn DDR_BA2 XXXX XXXX XXXX DDR_A12
3 DDR_BA0 DDR_A3 DDR_A8 XXXX DDR_A15 DDR_A0
2 DDR_A5 DDR_A9 DDR_CK DDR_A7 DDR_A10 DDR_RASn
1 VSS DDR_A6 DDR_CKn DDR_A2 DDR_BA1 DDR_CASn
