Pin map section location
AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
ZCE Pin Map [Section Middle - Top View]
G H J K L M
19 MMC0_CLK MMC0_DAT3 MII1_COL MII1_RX_ER MII1_RX_DV MII1_RX_CLK
18 MMC0_DAT0 MMC0_DAT2 MII1_CRS RMII1_REF_CLK MII1_TXD0 MII1_TXD1
17 MMC0_CMD MMC0_DAT1 XXXX MII1_TX_EN XXXX MII1_TXD3
16 USB0_DRVVBUS VDDS_PLL_MPU XXXX VDD_CORE XXXX VDDS
15 VDDSHV4 VDDSHV4 VSS VDD_CORE VSS VDDSHV5
14 XXXX VDDSHV4 VSS XXXX VSS VDDSHV5
13 XXXX VDD_CORE VDD_CORE XXXX VDD_CORE VDD_CORE
12 VSS VDD_CORE VDD_CORE VSS VDD_CORE VDD_CORE
11 VDD_CORE VSS VSS VSS VSS VSS
10 XXXX VSS XXXX XXXX XXXX VSS
9 VDD_CORE VSS VSS VSS VSS VSS
8 VSS VDD_CORE VDD_CORE VSS VDD_CORE VDD_CORE
7 XXXX VDD_CORE VDD_CORE XXXX VDD_CORE VDD_CORE
6 XXXX VDDS_DDR VSS XXXX VSS VDDS_DDR
5 VDDS_DDR VDDS_DDR VSS VDDS_DDR VSS VDDS_DDR
4 DDR_A11 DDR_VREF XXXX VDDS_DDR XXXX DDR_D11
3 DDR_CKE DDR_A14 XXXX DDR_DQM1 XXXX DDR_D10
2 DDR_RESETn DDR_CSn0 DDR_A1 DDR_D8 DDR_DQSn1 DDR_D12
1 DDR_ODT DDR_A13 DDR_VTP DDR_D9 DDR_DQS1 DDR_D13
12 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
