Pin map section location
AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
ZCE Pin Map [Section Right - Top View]
N P R T U V W
19 MII1_TX_CLK MII1_RXD1 MDC USB0_VBUS USB0_DP USB0_ID VSS
18 MII1_TXD2 MII1_RXD0 VDDA3P3V_USB0 USB0_CE USB0_DM GPMC_BEn1 GPMC_WPn
17 MII1_RXD3 MDIO VDDA1P8V_USB0 XXXX GPMC_CSn3 GPMC_AD15 GPMC_AD14
16 MII1_RXD2 VSSA_USB XXXX XXXX XXXX GPMC_CLK GPMC_AD9
15 VDDSHV5 XXXX GPMC_WAIT0 XXXX GPMC_CSn2 GPMC_AD8 GPMC_AD7
14 XXXX VSS XXXX VDDS GPMC_AD6 GPMC_CSn1 GPMC_AD5
13 XXXX VSS VDDSHV1 GPMC_AD13 GPMC_AD12 GPMC_AD4 GPMC_AD3
12 VSS VSS VDDSHV1 GPMC_AD10 GPMC_AD11 GPMC_AD2 XTALOUT
11 VDD_CORE VDD_CORE VDDSHV1 XXXX XXXX VSS_OSC XTALIN
10 XXXX XXXX VSS VSS VDDS_OSC GPMC_ADVn_ALE GPMC_AD0
9 VDD_CORE VDD_CORE VDDSHV1 XXXX XXXX GPMC_AD1 GPMC_OEn_REn
8 VSS VSS VDDSHV1 VDDS_PLL_CORE_LCD GPMC_WEn GPMC_BEn0_CLE GPMC_CSn0
7 XXXX VSS VDDSHV6 LCD_HSYNC LCD_VSYNC LCD_DATA15 LCD_AC_BIAS_EN
6 XXXX VDDSHV6 XXXX VDDS LCD_DATA13 LCD_DATA12 LCD_DATA14
5 VDDS_DDR XXXX VPP XXXX LCD_DATA10 LCD_DATA11 LCD_PCLK
4 DDR_D0 DDR_D1 XXXX XXXX XXXX LCD_DATA8 LCD_DATA9
3 DDR_DQM0 DDR_D4 DDR_D7 XXXX LCD_DATA7 LCD_DATA6 LCD_DATA5
2 DDR_D14 DDR_D2 DDR_DQSn0 DDR_D6 LCD_DATA1 LCD_DATA3 LCD_DATA4
1 DDR_D15 DDR_D3 DDR_DQS0 DDR_D5 LCD_DATA0 LCD_DATA2 VSS
