AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
U2 R2 LCD_DATA1
(5)
lcd_data1 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a1 1 O
pr1_mii0_txen 2 O
ehrpwm2B 3 O
pr1_pru1_pru_r30_1 5 O
pr1_pru1_pru_r31_1 6 I
gpio2_7 7 I/O
V1 R3 LCD_DATA2
(5)
lcd_data2 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a2 1 O
pr1_mii0_txd3 2 O
ehrpwm2_tripzone_input 3 I
pr1_pru1_pru_r30_2 5 O
pr1_pru1_pru_r31_2 6 I
gpio2_8 7 I/O
V2 R4 LCD_DATA3
(5)
lcd_data3 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a3 1 O
pr1_mii0_txd2 2 O
ehrpwm0_synco 3 O
pr1_pru1_pru_r30_3 5 O
pr1_pru1_pru_r31_3 6 I
gpio2_9 7 I/O
W2 T1 LCD_DATA4
(5)
lcd_data4 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a4 1 O
pr1_mii0_txd1 2 O
eQEP2A_in 3 I
pr1_pru1_pru_r30_4 5 O
pr1_pru1_pru_r31_4 6 I
gpio2_10 7 I/O
W3 T2 LCD_DATA5
(5)
lcd_data5 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a5 1 O
pr1_mii0_txd0 2 O
eQEP2B_in 3 I
pr1_pru1_pru_r30_5 5 O
pr1_pru1_pru_r31_5 6 I
gpio2_11 7 I/O
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 31
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
