Pin map section location
AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
ZCZ Pin Map [Section Right - Top View]
N P R T U V
18 USB0_DM USB1_CE USB1_DM USB1_VBUS GPMC_BEn1 VSS
17 USB0_DP USB1_ID USB1_DP GPMC_WAIT0 GPMC_WPn GPMC_A11
16 VDDA1P8V_USB0 USB0_ID VDDA1P8V_USB1 GPMC_A10 GPMC_A9 GPMC_A8
15 VDDA3P3V_USB0 USB0_VBUS VDDA3P3V_USB1 GPMC_A7 GPMC_A6 GPMC_A5
14 VSSA_USB VDDS GPMC_A4 GPMC_A3 GPMC_A2 GPMC_A1
13 VDD_CORE VDDSHV3 GPMC_A0 GPMC_CSn3 GPMC_AD15 GPMC_AD14
12 VDD_CORE VDDSHV3 GPMC_AD13 GPMC_AD12 GPMC_AD11 GPMC_CLK
11 VSS VDDSHV2 VDDS_OSC GPMC_AD10 XTALOUT VSS_OSC
10 VSS VDDSHV2 VDDS_PLL_CORE_LCD GPMC_AD9 GPMC_AD8 XTALIN
9 VDD_CORE VDDS GPMC_AD6 GPMC_AD7 GPMC_CSn1 GPMC_CSn2
8 VDD_CORE VDDSHV1 GPMC_AD2 GPMC_AD3 GPMC_AD4 GPMC_AD5
7 VSS VDDSHV1 GPMC_ADVn_ALE GPMC_OEn_REn GPMC_AD0 GPMC_AD1
6 VDDS VDDSHV6 LCD_AC_BIAS_EN GPMC_BEn0_CLE GPMC_WEn GPMC_CSn0
5 VDDSHV6 VDDSHV6 LCD_HSYNC LCD_DATA15 LCD_VSYNC LCD_PCLK
4 DDR_D5 DDR_D7 LCD_DATA3 LCD_DATA7 LCD_DATA11 LCD_DATA14
3 DDR_D4 DDR_D6 LCD_DATA2 LCD_DATA6 LCD_DATA10 LCD_DATA13
2 DDR_D3 DDR_DQSn0 LCD_DATA1 LCD_DATA5 LCD_DATA9 LCD_DATA12
1 DDR_D2 DDR_DQS0 LCD_DATA0 LCD_DATA4 LCD_DATA8 VSS
Copyright © 2011–2015, Texas Instruments Incorporated Terminal Configuration and Functions 17
