AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
Table 4-1. Pin Attributes (ZCE and ZCZ Packages) (continued)
BALL RESET BUFFER PULLUP
ZCE BALL ZCZ BALL TYPE BALL RESET RESET REL. ZCE POWER / HYS
PIN NAME [2] SIGNAL NAME [3] MODE [4] REL. STATE STRENGTH /DOWN TYPE I/O CELL [13]
NUMBER [1] NUMBER [1] [5] STATE [6] MODE [8] ZCZ POWER [9] [10]
[7] (mA) [11] [12]
W6 V4 LCD_DATA14
(5)
lcd_data14 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a18 1 O
eQEP1_index 2 I/O
mcasp0_axr1 3 I/O
uart5_rxd 4 I
pr1_mii_mr0_clk 5 I
uart5_ctsn 6 I
gpio0_10 7 I/O
V7 T5 LCD_DATA15
(5)
lcd_data15 0 I/O Z Z 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a19 1 O
eQEP1_strobe 2 I/O
mcasp0_ahclkx 3 I/O
mcasp0_axr3 4 I/O
pr1_mii0_rxdv 5 I
uart5_rtsn 6 O
gpio0_11 7 I/O
T7 R5 LCD_HSYNC
(7)
lcd_hsync 0 O Z L 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a9 1 O
gpmc_a2 2 O
pr1_edio_data_in3 3 I
pr1_edio_data_out3 4 O
pr1_pru1_pru_r30_9 5 O
pr1_pru1_pru_r31_9 6 I
gpio2_23 7 I/O
W5 V5 LCD_PCLK lcd_pclk 0 O Z L 7 VDDSHV6 / Yes 6 PU/PD LVCMOS
VDDSHV6
gpmc_a10 1 O
pr1_mii0_crs 2 I
pr1_edio_data_in4 3 I
pr1_edio_data_out4 4 O
pr1_pru1_pru_r30_10 5 O
pr1_pru1_pru_r31_10 6 I
gpio2_24 7 I/O
34 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
